A Proposal for a Market Research Study on the Worldwide Ultrasonic Flowmeter Market


Flow Research is proposing a new market study on the worldwide ultrasonic flowmeter market.  The study will be conducted by Flow Research.  The primary goal is to determine the size of the ultrasonic flowmeter market in 2006.  In addition, forecasts through 2011 will be included.  The study will be called The World Market for Ultrasonic Flowmeters, 3rd Edition.


The study has multiple purposes:

·        To determine worldwide market size and market shares for ultrasonic flowmeters in 2006

·        To forecast market growth for all types of ultrasonic flowmeters through 2011

·        To identify industries and applications where ultrasonic flowmeters are used, and to identify market growth areas

·        To provide a product analysis for the main companies selling into the ultrasonic flowmeter market

·        To provide strategies to manufacturers for selling into the ultrasonic flowmeter market

·        To provide company profiles of the main suppliers of ultrasonic flowmeters.


One main goal of this study is to determine the size of the ultrasonic flowmeter market worldwide in 2006.  This market continues to be one of the fastest growing flowmeter markets, which is driven in part by the expanding market for custody transfer of natural gas.


One important issue is the growth in the contrast between transit time and Doppler flowmeters. While Doppler flowmeters remain one of the best solutions for dirty liquids, transit time flowmeters have been showing faster growth in recent years. Much of the new product development is going into transit time meters. Transit time flowmeters are typically more accurate than Doppler meters, and multipath transit time meters are widely used for custody transfer of natural gas. This study will also look at growth in the hybrid flowmeter market.


This study will also examine the growing use of ultrasonic flowmeters for gas flow measurement. Custody transfer of natural gas is a fast growing market, especially with the increased popularity of natural gas as an energy source, and due to the rising price of both oil and natural gas. Custody transfer is one of a number of gas applications that are boosting sales of ultrasonic flowmeters.


Steam flow measurement is a new frontier for ultrasonic flowmeters. Currently, this market is dominated by differential pressure (DP) and vortex flowmeters. However, as the technology improves, this is becoming a growth area for ultrasonic flowmeters. Steam flow measurement is growing in importance as companies look to increase energy efficiency and cut energy costs. The high accuracy and reliability of ultrasonic meters make this an attractive option for some steam flow applications.

Background of Study

There are two main types of ultrasonic flowmeters: transit time and Doppler.  A transit time ultrasonic flowmeter has both a sender and a receiver.  It sends two ultrasonic signals across a pipe at an angle: one with the flow, and one against the flow.  The meter then measures the “transit time” of each signal.  When the ultrasonic signal travels with the flow, it travels faster than when it travels against the flow.  The difference between the two transit times is proportional to flowrate.


Doppler flowmeters also send an ultrasonic signal across a pipe.  Instead of tracking the time the signal takes to cross to the other side, a Doppler flowmeter relies on having the signal deflected by particles in the flowstream.  These particles are traveling at the same speed as the flow. As the signal passes through the stream, its frequency shifts in proportion to the mean velocity of the fluid. A receiver detects the reflected signal and measures its frequency. The meter calculates flow by comparing the generated and detected frequencies. Doppler ultrasonic flowmeters are used with dirty liquids or slurries.  They are not used to measure gas or steam flow.


Ultrasonic flowmeters were first introduced for industrial use in 1963 by Tokyo Keiki (which later became Tokimec) in Japan.  Tokimec is located in Tokyo, Japan.  In 1972, Controlotron (Hauppauge, New York) became the first U.S. manufacturer to market ultrasonic flowmeters in the United States.  In the late 1970s and early 1980s, both Panametrics (Waltham, Massachusetts) and Ultraflux (Poissy Cedex, France) experimented with the use of ultrasonic flowmeters to measure gas flow.  Initially, ultrasonic flowmeters were not well understood, and were sometimes misapplied.  Many technological improvements have been made in the past 10 years, and the limitations of ultrasonic meters are better understood.  Advances in transit time technology have broadened the types of liquids that transit time flowmeters can be used on. Many transit time meters today can handle liquids containing some impurities.

Rationale for Study

Since completing our first ultrasonic study in 2001, we have been following this market very closely.  We published the second edition of this study in 2003.  Many developments have been described in our quarterly report, the Market Barometer. Each issue of the Market Barometer includes an update on the ultrasonic flowmeter market. This new study builds on the knowledge we have gained over the years, but it is a completely new look at this market. For more information on the Market Barometer, go to www.worldflow.com


Key Issues Addressed


This study will address the key issues in the ultrasonic flowmeter market, including:


  • Growth in the ultrasonic transit time flowmeter market

  • Shipments of clamp-on, spoolpiece, and insertion meters

  • Comparison of portable vs. fixed ultrasonic flowmeters

  • The expanding use of ultrasonic flowmeters for custody transfer of natural gas

  • The emerging market for ultrasonic flowmeters in steam flow measurement

  • The market for Doppler and hybrid ultrasonic flowmeters

  • Mergers and acquisitions in the ultrasonic flowmeter market

Proposed Segmentation


The proposed segmentation for this study is as follows.


Geographic Segmentation:


·        North America

·        Europe, including Central Europe and FSU

·        Japan

·        Asia without Japan

·        Rest of World (Latin America, Africa, Middle East)


Ultrasonic Flowmeters by Technology Type

Text Box: What’s in this for my company?

·	See the emerging applications and where the growth is
·	Understand world and regional markets
·	Get to know your real competition
·	Learn what other suppliers manufacture, where, and for whom
·	The best information creates the best decisions

There are three kinds of ultrasonic flowmeters:


  • Transit time ultrasonic flowmeters

  • Doppler ultrasonic flowmeters

  • Hybrid ultrasonic flowmeters


Transit Time Ultrasonic Flowmeters by Number of Paths


Transit time flowmeters are distinguished by path type as follows:


  • Single path transit time ultrasonic flowmeters

  • Multipath transit time ultrasonic flowmeters


Multipath Transit Time Ultrasonic Flowmeters by Fluid Type


Multipath transit time flowmeters are distinguished by fluid type as follows:


  • Liquid

  • Gas

  • Steam

The multipath transit time ultrasonic flowmeter market for gas applications is equivalent to the fast-growing ultrasonic flowmeters for custody transfer of natural gas market.


Ultrasonic Flowmeters by Mounting Type


This study distinguishes between mounting types as follows:


  • Clamp-on ultrasonic flowmeters

  • Spoolpiece ultrasonic flowmeters

  • Insertion ultrasonic flowmeters


Clamp-On Flowmeters by Mounting Type


This study distinguishes between mounting types for clamp-on ultrasonic flowmeters as follows:


  • Portable clamp-on ultrasonic flowmeters

  • Fixed clamp-on ultrasonic flowmeters


Ultrasonic Flowmeters by Fluid Type

Ultrasonic flowmeters, including all types, are segmented in this study according to fluid type:

·        Text Box: What makes Flow Research so special?

·	Our only focus is flowmeters and process instrumentation.
·	We research the big three: manufacturing, distribution, and application.
·	Our end-user surveys and perspectives are unique to the industry.
·	Our Worldflow Monitoring Service keeps you up-to-date between studies.
·	We only succeed when you do.


·        Gas

·        Steam


Ultrasonic Flowmeters by Line Size

This study distinguishes line sizes for Ultrasonic flowmeters as follows:


  • < 2 inch

  • > 2 - 4 inches

  • > 4 – 8 inches

  • > 8 – 12 inches

  • > 12 – 20 inches

  • > 20 inches


Ultrasonic Flowmeters by Type:

Ultrasonic flowmeters are segmented in this study according to type:

·        Smart

·        Conventional


Ultrasonic Flowmeters by Communication Protocol

Ultrasonic flowmeters are segmented by the following protocols:

·        HART

·        Foundation Fieldbus

·        Profibus

·        Modbus

·        Proprietary Protocols

·        Other



Ultrasonic flowmeters by Industry

Ultrasonic flowmeters are used mainly in the process industries.  We propose to include the following industries in this study:

·        Oil and Gas Production, Transportation, and Distribution

·        Chemical

·        Pharmaceutical

·        Food & Beverage

·        Pulp & Paper

·        Metals & Mining

·        Power

·        Water & Wastewater

·        Other


Ultrasonic flowmeters by Sales Channels

The Ultrasonic flowmeter market will be segmented according to the following sales channels:

  • Direct Sales

  • Independent Representatives

  • Distributors

  • E-Business

Ultrasonic flowmeters by Customer Type

Text Box: How will the Founding Sponsor Program help me?

·	You can have your specific data requirements included in the study
·	You help determine the scope and final objectives
·	You receive periodic updates as the research progresses
·	You are among the first to receive final study results
·	You receive favorable pricing and other purchase terms

The Ultrasonic flowmeter market will be segmented according to the following customer types:

  • End-Users

  • OEMs

  • Systems Integrators

  • Engineers/Consultants


Ultrasonic flowmeters for Industrial District Heating Applications


This section analyzes the ultrasonic flowmeter market for industrial heating applications.  These numbers are separate from the numbers in the rest of the study, because this is a specialized niche market.

Publication Date

The target date for publication of this study is October 2007.

Founding Sponsorship

We are offering the opportunity for companies to become Founding Sponsors for this study.  Benefits of being a Founding Sponsor include being able to participate in determining study scope and direction, being sent regular updates on study progress, and receiving a favorable discount pricing package.  The Founding Sponsor program is explained on page nine.  We hope you will decide to become a Founding Sponsor for this study.

Please review the above segmentation and let us know if there is any additional segmentation you would like to see, or if you would like to propose changes to the existing segmentation.

Thank you in advance for your input, and we hope to hear from you!


Dr. Jesse Yoder is President of Flow Research Inc., a company he founded in 1998.  Dr. Yoder has 20 years’ experience as a writer and analyst in process control and instrumentation.  Since 1990, he has written more than 100 market research studies, most of them in the area of flow and instrumentation.  Some of the recent and currently scheduled Flow Research studies are as follows:


Volume I: The World Market for Coriolis Flowmeters, 3rd Edition  (2007)

Volume II: The Global Market for Magnetic Flowmeters, 3rd Edition  (September 2005)

Volume III: The World Market for Ultrasonic Flowmeters, 3rd Edition  (2007)

Volume IV: The World Market for Vortex Flowmeters, 3rd Edition  (March 2006)

Volume V: The World Market for DP Flowmeters and Primary Elements  (January 2007)

Volume VI: Worldwide Survey of Flowmeter Users, 2nd Edition  (January 2006)

Volume VII: The World Market for Positive Displacement Flowmeters  (2002)

Volume VIII: The World Market for Turbine Flowmeters  (2002)

Volume IX: The World Market for Pressure Transmitters, 2nd Edition (July 2007)

Volume X: The World Market for Flowmeters (includes all flow technologies)  (2008)

Volume XI: The World Market for Gas Flow Measurement  (September 2004)

Volume XII: The World Market for Steam Flow Measurement (March 2007)

Volume XIII: The World Market for Mass Flow Controllers (September 2007)

The Market for Temperature Sensors in the Americas, 2nd Edition  (May 2006)

The Market for Temperature Transmitters in the Americas, 2nd Edition  (November 2006)

These studies are described at http://www.flowresearch.com/flow.htm
